XM-3015W

    The FEC new generation product – Xmonitor, which redesigned with XPPC, provides three different installation methods. Respectively is the integrated type mounted on the monitor, the arm type fixed on the stand, and the pole type with an independent extending FEC pole.
    Compare
    Anfrage

    Quick find
    proimages/Web_Data/product/06-Monitors/XM-3015W/XM-3015_1.png
    01

    2nd Monitors Arm type

    proimages/Web_Data/product/06-Monitors/XM-3015W/XM-3015W_2.png
    02

    2nd Monitors Pole Type

    15” | 15.6”

    proimages/Web_Data/product/06-Monitors/XM-3015W/XM-3015W_4.png
    03

    2nd Monitors

    Arm Type / Integrated Type / Pole Type

    proimages/Web_Data/product/06-Monitors/XM-3015W/XM-3015W_5.png

    Specifications

    Display
    Display
    • 15.6" TFT , 1920 x 1080
    Touch
    Touch
    • Non-Touch
    • True-Flat PCAP
    Brightness
    Brightness
    • 300 nits
    MTBF
    MTBF
    • 50K Hours
    Speaker
    Speaker
    • 4ohm 2W (Available for AD board Version)
    Power
    Power
    • AD board Version:
      12V DC-in (Power From VGA, USB DP)
    • SMART DD Version:
      20V DC-in (Power From SMART DD)
    Mounting
    Mounting
    • Standalone
    • Arm Type
    • Pole Type
    • VESA 100 x 100 mm
    Certification
    Certification
    • FCC / CE Class B
    Appearance
    Appearance
    • Aluminum Die-casting + Plastic
    • Galaxy Grey
    Temperature
    Temperature
    • Operation: 0˚C ~ 40˚C (32˚F ~ 104˚F)
    • Storage: -20˚C ~ 60˚C (-4˚F ~ 140˚F)
    Dimensions (W x H x D)
    Dimensions (W x H x D)
    • Product: 368 x 272.5 x 315 mm
    • Carton: 492 x 168 x 488 mm
    Weight
    Weight
    • Display Only (Net): 3 Kg
    • Display with Stand (Net): 3.9 Kg
    • Display with Stand (Gross): 5.6 Kg
    Port
    Port
    • AD board Version:
      1 x Video Port
      1 x VGA (12V Power)
      1 x USB DP
      1 x USB 2.0 Type B
      1 x DC-in 12V
      1 x Line-in
    • Smart DD Version:
      1 x Smart DD in
      1 x Smart DD out
    Optional
    Optional
    • Compatible with XPOS Add-on device(Supports Device on Right Side)
    • 2 in 1 Sensor (Ambient Light, Proximity)
    • 2MP Front Camera
    • 2 x USB 2.0 Type A
