PP-9132W
產品介紹
01
22" Fanless Panel PC
AerPPC PP-9132W is an ultra slim modular All-in-One panel PC. It' s fanless design offer you a silent and dust free operating environment.
- Platform: Android OS
- Processor: RK-3568 Quad-Core Cortex A55
- System Storage: 64GB eMMC ; External Micro SD
02
Digital Information Signage
No matter using AerPPC or AerMonitor, FEC 22 inch series are beautiful displays with high resolution screens. With universal VESA wall mount design, they can be easily mounted on any flat surface!
03
Large Enterprise Environment
Large screen All in One Android Panel PC is perfected for digital signage, product display, industrial control system or apply with self-ordering system.
04
FEC ANDROID
FEC provides a complete series of Android POS. From 10" to 22" in for lightweight usage, wall-mount as digital display or with stand for different types of POS terminals.
規格
處理器
- Rock chip RK-3568 Quad-core Cortex-A55 up to 2.0GHz
記憶體
- 4GB DDR3 On Board
儲存裝置
- 64GB Built-in eMMC
無線裝置
- WIFI 802.11 ac & BT 4.2 (Optional)
喇叭
- 2 x 2W Internal Speaker
顯示器
- 22" TFT, 1920 x 1080
觸控
- True-Flat PCAP
亮度
- 250 nits
平均故障間隔時間
- 50K Hours
像機
- 2MP Front Camera (Optional)
電源供應
- 20V / 90W or 20V / 130W External Adapter
作業系統
- Android 12
壁掛
- VESA 100 x 100 mm
認證
- FCC / CE Class B
外觀
- Aluminum Die-casting + Plastic
- Black with Silver Trim
溫度
- Operation: 0˚C ~ 40˚C (32˚F ~ 104˚F)
- Storage: -20˚C ~ 60˚C (-4˚F ~ 140˚F)
尺寸 (寬 x 高 x 深)
- Product: 513 x 309 x 388 mm
- Carton: 662 x 440 x 210 mm
重量
- Net 5.7 kg
- Gross 7 kg
連接埠
- 1 x20V DC Input
- 1x RJ45 Gigabit LAN
- 1x Video Port
- 1x RJ11 Cash Drawer (12V or24V)
- 1 x SD/TF Card Slot (Max: 128GB)
- 1x Recovery button
- 2 x USB 2.0 ,1 x USB 3.0,1 x USB 3.0 (OTG)
- 2x RJ45 (COM1, COM2) RS232 (0V/5V/12V)
選擇搭配
- 2 x USB2.0
- 1 x DB9 (COM3)
- 1x 24V DC Output
