PP-9635
Specifications
CPU
- Intel® Celeron J1900 2M Cache, up to 2.42 GHz
Memory
- 4GB Standard, Max 8GB (1 x 204-pin DDR3L)
Storage
- 1 x 2.5” SATA HDD or SSD
Speaker
- 2 x 2W Internal Speaker
Display
- 15” TFT, 1024 X 768
Touch
- True-Flat PCAP
Brightness
- 350 nits
MTBF
- 50K Hours
Power
- 12V / 90W External Adapter
- 12V / 150W External Adapter
OS
- POSReady 7
- POSReady 2009
- Windows 10 Pro
- Windows 10 IoT Enterprise
Mounting
- VESA 100 x 100 mm
Certification
- FCC / CE Class B
Appearance
- Aluminum Die-Casting + Plastic
- Black with Silver Trim
Temperature
- Operation: 0˚C ~ 40˚C (32˚F ~ 104˚F)
- Storage: -20˚C ~ 60˚C (-4˚F ~ 130˚F)
Dimensions (W x H x D)
- Product: 366 x 334 x 220 mm
- Carton: 480 x 460 x 320 mm
Weight
- Net: 4.9 Kg
- Gross: 8 Kg
Port
- 1 x PUSB 24V
- 1 x RJ11 (12V / 24V) Supports Two Cash Drawers
- 1 x RJ45 (COM1) RS232 with RI / 5V / 12V Selectable
- 1 x VGA
- 4 x USB Type A (3 x USB 2.0, 1 x USB 3.0)
- 1 x RJ45 GigaLAN
- 1 x 12V DC Output
- Side I/O Interface:
1 x USB 2.0 Type A - Internal Expansion:
1 x Mini PCIe
Optional
- Type A: 2 x DB9 (COM 2, COM 4) RS232 with RI / 5V / 12V Selectable
- Type B: 2 x PUSB 12V,
- Type C: 2 x USB 2.0 Type A
